The White-Rodgers 1361-102 3/4 in. 2-wire zone valve is designed for quiet, reliable performance in HVAC and hydronic heating systems. Built with a durable stainless steel valve stem and body, this valve supports systems up to 50 PSI and water temperatures up to 240°F. It features built-in auxiliary contacts for burner or circulator relay control, a screw terminal wiring panel for easy installation, and a removable motor assembly that allows servicing without draining the system.

Features:

• 3/4 in. 2-wire zone valve with sweat connections
• Quiet operation for residential and commercial HVAC systems
• Stainless steel valve stem and body for long-lasting durability
• Built-in auxiliary contacts for burner or circulator relay control
• Screw terminal wiring panel with auxiliary switch for easy wiring
• Supports up to 50 PSI system pressure
• Maximum water temperature of 240°F
• Motor can be removed without draining the system
• Automatic recycling manual operator shows valve position at all times
• Compatible with 24 VAC systems

Details:

• Model: 1361-102
• Brand: White-Rodgers
• Valve Type: Zone Valve
• Size: 3/4 Inch
• Material: Stainless Steel
• Finish: Stainless Steel
• Inlet Connection Type: Sweat
• Outlet Connection Type: Sweat
• Connector Type: Sweat
• Thread Type: NPT
• Thread Size: 3/4 in. NPT
• Number of Ports: 2
• Voltage: 24 VAC
• Current Rating: 2.0 A at 24 VAC
• Thermostat Circuit Rating: 0.2 A at 24 VAC
• Maximum System Pressure: 50 PSI
• Maximum Differential Across Valve: 15 PSI
• Maximum Water Temperature: 240°F
• Flow Capacity Cv: 23.5
• Equivalent Feet of Friction Loss: 2.5
• Dimensions: 4.63 x 2.63 x 5.63 in.
• Weight: 2.5 lb
• UPC: 786710003981
• Unit Count: 1
• Certifications: ASME, ASTM, NSF, ULC, UL, ANSI, ISO 9001
